KVC900N Multi Ionization Vacuum Gauge Controller
Vacuum Gauge Controller
Product
- As a High Vacuum Gauge Controller suitable for industrial coding, analysis equipment, and high vacuum use, it can measure from high vacuum to atmospheric pressure. As a multi controller, it can use 2CH in high vacuum and up to 2CH in low vacuum, and reduce installation costs.
- When using the KVC500 ATM Gauge Sensor, it can be used in a variety of gas atmospheres.
SPECIFICATION
| Analog output |
ION : Log Scale ( -10 ~ -2Vdc ) |
| SET POINT RELAYS |
6 or 8 Point SPST |
| POWER REQUIRED | A( 220V ( AC 110V Optional ) ) 120VA |
| OPTIONAL |
RS232 / 485 ASCII, |
| Application Sensor |
ION Gauge, KVC400 SHIM Gauge, |
| Sensor Fitting Size |
1/8NPT, 15mmO,D, NW16KF, |
| ION Gauge Size |
NW25KF, 2.75CF, 19mmO.D |
| Bayard-Alpert Vacuum Gauge |
1.0E-10 to 1.0-02 Torr |
| ATM SHIM Gauge Range |
KVC500 : 1.0E-03 to 1500 Torr |
