KVC3300N SHIM Vacuum Gauge Controller
Vacuum Gauge Controller
Product
-
The Series KVC3300N measures vacuum according to the user’s use and utilizes output to control various vacuum systems and pressures.
The vacuum value automatically switches to Torr or mTorr.
SPECIFICATION
| Analog output |
Log scale ( -3 ~ 3Vdc ) |
| SET POINT RELAYS | 2 Point SPST (5A / 30VDC ,5A / 250VAC ) |
| POWER REQUIRED | AC85 ~ 265V / 20VA 50 ~ 60 Hz |
| OPTIONAL |
RS232 / 485 ASCII, |
| Application Sensor | KVC400 SHIM Gauge Sensor |
| Sensor Fitting Size |
1/8NPT, 15mmO,D, NW16KF, NW25KF |
| Measurement Range |
1.0-3 to 1000Torr |
