CF可旋转法兰有波纹管附感应器(美规)
气动式Y型阀门
| select | |||
| Model No. | YVBS-CR16-P | YVBS-CR35-P | |
| Parts No. | 304109130216 | 304113130216 | |
| A"(mm) | 4.70"(119.4) | 5.24"(133) | |
| B"(mm) | 4.73"(120) | 6.17"(156.8) | |
| C"(mm) | 2.24"(56.8) | 2.98"(75.8) | |
| O.D. | 0.75"(19.05) | 1.50"(38.1) | |
| Select | Model No. | Parts No. | A"(mm) | B"(mm) | C"(mm) | O.D. |
| YVBS-CR16-P | 304109130216 | 4.70"(119.4) | 4.73"(120) | 2.24"(56.8) | 0.75"(19.05) | |
| YVBS-CR35-P | 304113130216 | 5.24"(133) | 6.17"(156.8) | 2.98"(75.8) | 1.50"(38.1) |
